Color LED
- High energy efficacy in μmol/J
- Deep blue (450 nm), hyper red (660 nm) and Far red (730 nm) to provide the light for the photosynthesis
- Q90 Report are available
- Application：Horticulture Lighting /Architectural Lighting/ Phototherapy
Description | Color | Part Number | Test current | Φe/mW | Wavelength | PPF（Typ）@IF μmol/s | PPE（Typ）@IF μmol/J | Angle |
Horti 3535 | Royal Blue | RF-AL-C3535L2K1RB-08 | 350mA | 650-850 （Typ690） | 445-455 | 2.5-2.9 (Typ2.62) | 2.6-2.9 (Typ2.72) | 120° |
Royal Blue | RF-AL-C3535L2K1RB-06 | 350mA | 650-850 （Typ731） | 445-455 | 2.6- 3.0 (Typ2.74) | 2.7-3.0 (Typ2.85) | 120 | |
Deep Red | RF-AL-C3030L2K1DR-05 | 350mA | 400-550 （Typ475） | 650-670 | 2.5-2.8 (Typ2.65) | 3.4-3.9 (Typ3.73) | 120° | |
Deep Red | RF-AL-C3030L2K1DR-04 | 350mA | 400-550 （Typ505） | 650-670 | 2.6-3.0 (Typ2.88) | 3.5-4.0 (Typ3.90) | 120° | |
Deep Red | RF-AL-C3030L2K1DR-06 | 350mA | 450-600 （Typ540） | 650-670 | 2.6-3.0 (Typ3.14) | 3.7-4.2 (Typ4.28) | 120° | |
Deep Red | RF-AL-C3030L2K1DR-01/03 | 350mA | 500-600 （Typ545） | 650-670 | 2.8-3.3 (Typ3.00) | 4.2-4.7 (Typ4.45) | 120° | |
Deep Red | RF-AL-C3030L2K1DR-09 | 350mA | 500-600 （Typ565） | 650-670 | 2.9-3.4 (Typ3.10) | 4.3-4.8 (Typ4.66) | 120 | |
Far Red | RF-AL-C3030L2K1FR-04 | 350mA | 350-500 （Typ415） | 720-740 | 2.4-2.7 (Typ 2.64) | 3.2-3.6 (Typ 3.71) | 120 | |
Far Red | RF-AL-C3030L2K1FR-00/01 | 350mA | 400-500 （Typ430） | 720-740 | 2.5-2.8 (Typ 2.68) | 3.6-3.9 (Typ 3.75) | 120 |
If you're interested in our products or service, you can choose to leave your information here, and we will be in touch with you shortly.
- Deep blue (450 nm), hyper red (660 nm) and Far red (730 nm) to provide the light for the photosynthesis
- Q90 Report are available
- Application：Horticulture Lighting /Architectural Lighting/ Phototherapy
- Provide UVA full band coverage program and application solutions
- Customized solutions can be provided according to customer applications
- Full-power, high-brightness series coverage to meet different applications.
- Good color consistency, good brightness consistency
- WPE 4.5% for mass-produced series products
- Low thermal resistance, low attenuation, long life up to 10000H.
- Provide UVA full band coverage program and application solutions.
- Provide customized products according to customer's application
- Full power, high brightness series coverage to meet different applications
- Sterilization effect up to 99.99%, and no bacteria growth
- Mass production series products WPE 4.5%
- Low thermal resistance, low attenuation, long life up to 10000H.
- Provide UVA full band coverage program and application solutions
- Customized solutions can be provided according to customer applications
- Full-power, high-brightness series coverage to meet different applications.
- Good color consistency, good brightness consistency
- WPE 4.5% for mass-produced series products
- Low thermal resistance, low attenuation, long life up to 10000H.
- Provide UVA full band coverage program and application solutions
- Customized solutions can be provided according to customer applications
- Full-power, high-brightness series coverage to meet different applications.
- Good color consistency, good brightness consistency
- WPE 4.5% for mass-produced series products
- Low thermal resistance, low attenuation, long life up to 10000H.
- Provide UVA full band coverage program and application solutions
- Customized solutions can be provided according to customer applications
- Full-power, high-brightness series coverage to meet different applications.
- Good color consistency, good brightness consistency
- WPE 4.5% for mass-produced series products
- Low thermal resistance, low attenuation, long life up to 10000H.
- Provide UVA full band coverage program and application solutions
- Customized solutions can be provided according to customer applications
- Full-power, high-brightness series coverage to meet different applications.
- Good color consistency, good brightness consistency
- WPE 4.5% for mass-produced series products
- Low thermal resistance, low attenuation, long life up to 10000H.
- Provide UVA full band coverage program and application solutions
- Customized solutions can be provided according to customer applications
- Full-power, high-brightness series coverage to meet different applications.
- Good color consistency, good brightness consistency
- WPE 4.5% for mass-produced series products
- Low thermal resistance, low attenuation, long life up to 10000H.
- 1W/㎡ high heat dissipation ceramic3535
- High photosynthetic efficiency
- Q90≥36KH
-Main wavelength are 450/660/730nm, covering PAR 400-700nm, can do other custom special wavelength from 365-800nm
-0.2-0.5 W Power，PCT2835, single color light
- High power,High brightness
- Good reliability
- Rich Color
- Uniform color
- Customizable Specification
- High power,High brightness
- Good reliability
- Rich Color
- Uniform color
- Customizable Specification
- Can be applicated in Plant lighting, Landscape lighting, Stage lighting
- Support customized products based on the Ceramic 3535 package
- Can be applicated in Plant lighting, Landscape lighting, Stage lighting
- Support customized products based on the Ceramic 3535 package
- MSL3
- Good consistency of RGB mixed white light;
- can be divided by color light and mixed white light;
- LM-80
- High energy efficacy in μmol/J
- Deep blue (450 nm), hyper red (660 nm) and Far red (730 nm) to provide the light for the photosynthesis
- Q90 Report are available
Application：Horticulture Lighting /Architectural Lighting/ Phototherapy
- Simple structure, easy to use;
- Excellent product performance, beautiful price;
- Widely used in biological testing, nail art and other fields
- Simple structure, easy to use;
- Excellent product performance, high cost performance.
- Long life, stable light color; High efficiency;
- High air tightness and corrosion resistance; High reliability in high temperature and humidity environment;
- All kinds of color light and full spectrum white light for choice, and can be customized according to the needs of development;
- Medium and small power, full range of products to meet various needs;
-2835 color series (covering 450/660/730 band, can be customized to cover PAR400-800nm);
-2835 chip plus phosphor color series (low cost, customizable plant lighting band and spectrum);
-2835 white light full spectrum series (simulated sunlight spectrum or customized spectrum, to meet the growth cycle of various plants, can also improve the humanized lighting environment of plant factories).
- Main wavelength are 450/660/730nm, customizable view angle with 30°、60°、120° . With light concentration or wide illumination characteristics, no need to equip with other optical components.
- 1.0W Power, EMC3030, single color light
- Long life, stable light color;
- High air tightness and corrosion resistance;
- Various light colors, and can be customized development according to need.
-Rich and diverse products, can provide customers with customized solutions;
- Used in residential district advertising board project, bus and subway advertising board, building display project, exhibition center, etc.;
- LM-80。
- Experience in cooperation with large factories without quality problems;
- Rich in color;
- Can be developed on site.
- Experience in cooperation with large factories without quality problems;
- Rich in color;
- Can be developed on site.
- Dachang cooperation experience, no quality problems;
- colorful;
- Can be fixed point development.
- Color temperature can be customized;
- High integration, rich color, excellent mixing effect;
- Compact structure to meet the dense arrangement of lamp beads;
- A variety of light color adjustable and controllable.
- Global initiative, patented products (counterfeiting will be investigated);
- High integration, rich color, excellent mixing effect;
- Compact structure to meet the dense arrangement of lamp beads;
- Light color adjustable and controllable, a product can achieve unlimited possibilities.
