Color LED
Features
- Ceramics Package.
- Extremely wide viewing angle.
- Suitable for all SMT assembly and solder process.
- Available on tape and reel.
Moisture sensitive level:Level1.
RoHS compliant.
Application
- Article color lamp,lamp belt
- Plant lighting,Landscape lighting, Stage photography light.
- Hotels, markets, ofices, household and other indoor uses.
- General use.
Product | Power | Color | Ta @25℃(TYP.) | Max current (mA) | Lens(mm) | viewing angle （°） | ESD withstand voltage()HBM | ||||
IF(mA) | vf(V) | Flux/lm @4000K Ra70 | Ra | CCT/Wd | |||||||
RF-AL-C3535L2K1RB-04 | 3-5W | Royal Blue | 350 | 2.6-3.4 | 20-35 | / | 445-460 | 1500 | 3.06 | 120 customizable 30/60/90 | 2000 |
RF-AL-C3535L2K1RB-03 | 3-5W | Blue | 350 | 2.6-3.4 | 40-60 | / | 465-475 | 1500 | 3.06 | 120 customizable 30/60/90 | 2000 |
RF-AL-C3535L2K1CN-00 | 3-5W | Ice Blue | 350 | 2.6-3.4 | 70-140 | / | 480-500 | 1500 | 3.06 | 120 customizable 30/60/90 | 2000 |
RF-AL-C3535L2K1GR-03 | 3-5W | Green | 350 | 2.6-3.4 | 120-160 | / | 520-530 | 1500 | 3.06 | 120 customizable 30/60/90 | 2000 |
RF-AL-C3535L2K1YU-00 | 1-3W | Amber | 350 | 2.0-2.6 | 40-70 | / | 585-595 | 1000 | 3.06 | 120 customizable 30/60/90 | 2000 |
RF-AL-C3535L2K1OR-02 | 1-3W | Orange-Red | 350 | 1.8-2.6 | 250-500mW | / | 600-610 | 1000 | 3.06 | 120 customizable 30/60/90 | 2000 |
RF-AL-C3535L2K1RE-03 | 1-2W | Red | 350 | 1.8-2.4 | 60-90 | / | 620-625 | 800 | 3.06 | 120 customizable 30/60/90 | 2000 |
RF-AL-C3535L2K1OR-01 | 1-3W | Deep Red | 350 | 1.8-2.4 | 200-500mW | / | 630-650 | 1000 | 3.06 | 120 customizable 30/60/90 | 2000 |
RF-AL-C3535L2K1IR-03 | 1-2W | IR | 700 | 1.0-1.6 | 400-700mW | / | 800-810(WP) | 1200 | 3.06 | 120 customizable 30/60/90 | 2000 |
RF-AL-C3535L2K1IR-02 | 1-2W | IR | 700 | 1.0-1.6 | 450-700mW | / | 825-835(WP) | 1200 | 3.06 | 120 customizable 30/60/90 | 2000 |
RF-AL-C3535L2K1IR-01 | 1-2W | IR | 350 | 1.0-1.6 | 250-400mW | / | 845-855(WP) | 1000 | 3.06 | 120 customizable 30/60/90 | 2000 |
RF-AL-C3535L2K1FIR-01 | 1-2W | FIR | 350 | 1.0-1.6 | 250-500mW | / | 900-910(WP) | 1000 | 3.06 | 120 customizable 30/60/90 | 2000 |
RF-AL-C3535L2K1FIR-00 | 1-2W | FIR | 700 | 1.0-1.8 | 450-850mW | / | 930-950(WP) | 1500 | 3.06 | 120 customizable 30/60/90 | 2000 |
RF-AL-C3535L2K1DR-09 | 1-3W | Deep Red | 700 | 1.8-2.1 | 1000-1300mW PPE：4.35umol/J@700mA | / | 655-665(WP) | 1500 | 3.06 | 120 customizable 30/60/90 | 2000 |
RF-AL-C3535L2K1DR-02 | 1-3W | Deep Red | 700 | 1.8-2.1 | 950-1250mW PPE：4.15umol/J@700mA | / | 655-665(WP) | 1000 | 3.06 | 120 customizable 30/60/90 | 2000 |
RF-AL-C3535L2K1DR-06-A | 1-3W | Deep Red | 350 | 1.8-2.1 | 500-600mW PPE：4.10umol/J@350mA | / | 655-665(WP) | 1000 | 3.06 | 120 customizable 30/60/90 | 2000 |
RF-AL-C3535L2K1FR-01-A | 1-3W | Far Red | 350 | 1.8-2.2 | 400-550mW YPE：3.65umol/J@350mA | / | 725-735(WP) | 1000 | 3.06 | 120 customizable 30/60/90 | 2000 |
RF-AL-C3535L2K1RB-06 | 5-10W | Royal Blue | 700 | 2.6-3.0 | 1400-1600mW PPE：2.67umol/J@700mA | / | 445-455 | 2000 | 3.06 | 120 customizable 30/60/90 | 2000 |
